INTEL OEM SINGLE BOARD COMPUTER COLLECTION Intel introduced its first Single Board Computer in 1976.
|
 |
During 1975 Digital Equipment Corporation (DEC) introduced the LS1-11, a complete 16 bit microcomputer system (without RAM included) on a single board with an under $ 1000 price. Intel Started working on a more complete and cheaper single board design. In February, 1976, the commercialization of the Single Board Computer 80/10 was announced by intel (See Microcomputer Digest article), the production of which had already begun a few weeks earlier. Starting April 6, 1976, Intel began a major promotional campaign by organizing 45 conferences in several cities in the United States and Canada (see Intel brochure diffused during the conferences) . The IT press reported on this Intel presentation (See Electronic Design article). A two-page spread advertisement on the SBC 80/10 appeared in leading trade magazines from April to June 1976. (See Computer Design advert). The very first Single Boards Computer 80/10 produced (1st half of 1976) are easily recognizable because they comprise several white ceramic components. Here we've got one of them manufactured the last week of March 1976 (very hard to find today). |
||||
Single Board Computer |
||||
 |
||||
iSBC MODEL |
80/10 - PWA 1000618-02 (Second Serie) | RAM |
1K byte |  |
CPU |
C8080A | EPROM |
4 x Intel C8708 | |
ADDITIONAL MODULES |
Not present | MFG. DATE |
13-1976 / © 1975 | |
Last location : Pauma Valley, California, USA
 |
||||
iSBC MODEL |
80/20 - PWA 1000818-01B | RAM |
2K byte | |
CPU |
P8080A-2 | EPROM |
4 x Intel B2716 | |
ADDITIONAL MODULES |
Not present | MFG. DATE |
31-1977 / © 1976 | |
Last location : Toronto, Canada
Last location : Détroit, Michigan, USA
Single Board Computer |
||||
 |
||||
iSBC MODEL |
80/10A - PWA 1000949-03C | RAM |
1K byte | |
CPU |
D8080A | EPROM |
4 x Intel D2716 | |
ADDITIONAL MODULES |
Not present | MFG. DATE |
02-1979 / © 1978 | |
Last location : West-Chester, Ohio, USA
Single Board Computer |
||||
 |
||||
iSBC MODEL |
80/10B - PWA 142722-002 | RAM |
1K byte | |
CPU |
D8080A | EPROM |
4 x Intel D2732 | |
ADDITIONAL MODULES |
Not present | MFG. DATE |
12-1981 | |
Single Board Computer |
||||
 |
||||
iSBC MODEL |
80/16D - PWA-144068-007 | RAM |
2K byte | |
CPU |
P8080A-1 | EPROM |
6 x Intel 2764-4 | |
ADDITIONAL MODULES |
Not present | MFG. DATE |
09-1984 | |
Last location : North Lawrence, Ohio, USA
Last location : San Francisco, California, USA
Last location : Leeuwarden, Netherlands
|
||||
 |
||||
iSBC MODEL |
80/05 - PWA 1001299-07 |
RAM |
512 bytes | |
CPU |
D8085AH |
EPROM |
2 x TMS 2708JL-45 | |
EXPENSION MODULES |
Not Present |
MFG. DATE |
01-1984 | |
Last location : New Lennox, Illinois, USA
Last location : Sevierville, Tennesse, USA
 |
||||
iSBC MODEL |
80/30 - PWA 142751-Rev |
RAM |
16K bytes | |
CPU |
D8085AH |
EPROM |
2 x Intel D2716-1 | |
EXPENSION MODULES |
Not Present | MFG. DATE |
07-1988 | |
Last location : Mokena, Illinois, USA
Last location : Richardson, Texas, USA
Single Board Computer |
||||
 |
||||
iSBC MODEL |
86/14 - PWA 143799-017 |
RAM |
32K bytes | |
CPU |
D8086-2 |
EPROM |
4 x NEC D2732D | |
EXPENSION MODULES |
iSBC 350 (Parallel Multimodule) | MFG. DATE |
15-1982 | |
Last location : Asheville, North Carolina, USA
Last location : Rio Rancho, New Mexico, USA
 |
||||
iSBC MODEL |
86/30 - PWA 143799-026 |
RAM |
128K bytes | |
CPU |
D8086-2 |
EPROM |
4 x Intel D27128A | |
EXPENSION MODULES |
iSBC 337 (Multimodule Processors CPU+FPU) iSBC 304 (128k RAM Multimodule) |
MFG. DATE |
08-1984 | |
Last location : Phoenix, Arizona, USA  |
||||
iSBC MODEL |
86/05A - PWA 147013-005 |
RAM |
8K bytes | |
CPU |
D8086-2 |
EPROM |
4 x Intel D27128A-2 | |
EXPENSION MODULES |
iSBC 337 (Multimodule Processors CPU+FPU) | MFG. DATE |
27-1989 | |
Last location :
Wroclaw, Poland
Last location : Salisbury, Massasuchet, USA
|
||||
 |
||||
iSBC MODEL |
88/25 - PWA 143369-004 |
RAM |
4K bytes | |
CPU |
D8088-2 |
EPROM |
4 x Intel D27256-2 | |
EXPENSION MODULES |
Not present | MFG. DATE |
03-1984 | |
Last location : Machesney Park, Illinois, USA
Last location : Klamath Falls, Oregon, USA
 |
||||
iSBC MODEL |
286/12 - PBA 149101-002 |
RAM |
1M bytes | |
CPU |
A80286-10 & D80287-10 FPU on board |
EPROM |
2 x Intel D27256-2 | |
EXPENSION MODULES |
iSBC 324 (1Mb RAM Multimodule) | MFG. DATE |
49-1987 | |
Last location : Phoenix, Arizona, USA
Single Board Computer 201 |
||||
 |
||||
MODEL |
iSBC 201 - PWA 1000467 |
CHIPS |
C3002, C3001, C3205, D3604, P8212 | |
TYPE |
FLOPPY DISK CONTROLLER
|
MFG. DATE |
02-1976 / © 1975 | |
Single Board Computer 204 |
||||
 |
||||
MODEL |
iSBC 204 - PWA 1001554-04 B |
CHIPS |
D8257, C8271, P8212, 82-104 | |
TYPE
|
UNIVERSAL FLOPPY DISK CONTROLLER
|
MFG. DATE
|
23-1978 / © 1978 | |
Single Board Computer 208 |
||||
 |
||||
MODEL |
iSBC 208 - PWA 145977-001 B |
CHIPS |
D8272A, P8237A-5 | |
TYPE
|
FLEXIBLE DISK CONTROLLER
|
MFG. DATE
|
19-1983 | |
Single Board Computer 116 |
||||
 |
||||
MODEL |
iSBC 116 - PWA 1000924-02 C |
CHIPS |
CP8255A, P8212, P8251A, D3222, C2708 | |
TYPE
|
COMBINATION MEMORY & I/O
|
MFG. DATE
|
05-1978 / © 1976 | |
Single Board Computer 416 |
||||
 |
||||
MODEL |
iSBC 416 - PWA 1000669-02 E |
CHIPS |
MCM2708C | |
TYPE
|
16 K PROM / ROM MEMORY EXPANSION
|
MFG. DATE
|
43-1979 / © 1976 | |
Single Board Computer 544 |
||||
 |
||||
MODEL |
iSBC 544 - PWA 143472-002 B |
CHIPS |
P8085AH, P8155H, D8202A, D8251A, P8253 | |
TYPE
|
INTELLIGENT COMMUNICATIONS CONTROLLER
|
MFG. DATE
|
37-1983 | |
